AquaCraft Wildcat Catamaran Brushless 2.4GHz RTR
This is the electric powered, 2.4GHz radio controlled, ready to run
Wildcat Catamaran from AquaCraft.
For ages 14 and over.
FEATURES: Hull: Molded ABS plastic with transom drain plug and preapplied
graphics
Motor: 1800kV brushless outrunner
Motor Mount: Water cooled aluminum with transom mounted water
pickup
Drive System: Surface drive propeller system with 1/8" (3.2mm) shaft
Radio: Tactic 2.4GHz TTX240 2-channel with fail safe, steering and
throttle trim and servo reversing and steering rate adjustment
Electronic Speed Control: 50A water coooled, LiPO compatible, low
voltage compatible and Deans Ultra connector
Propeller: Two blade 42mm diameter FRP (fiber reinforced plastic)
Rudders: Two aluminum construction with breakaway shear bolt design
Warranty: AquaCraft will warrant your model for 90 days after the
purchase from defects in materials or workmanship of original
manufacture. AquaCraft, at their option, will repair or replace at
no charge, the incorrectly made part. This warranty does not cover
damage caused by crash, abuse, misuse, alteration or accident.
INCLUDES: RTR Wildcat Catamaran with Motor, Radio, Steering Servo, ESC, Stand
and Instruction Manual
REQUIRES: AA Batteries: Four for transmitter
LiPo Battery: 3S 11.1V at least 2000mAh
Battery Charger: Compatible with selected battery
LiPo Charging Sack and Shore Equipment
SPECS: Catamaran;
Length: 26.5" (673mm)
Overall: 29" (737mm)
Beam: 9" (229mm)
Height: 5.5" (140mm)
Weight: 32oz. (907grams) RTR w/o batteries
Motor;
KV Rating: 1800kv
Operating Current: 3.8A, 8V/DC (without loading, 8V/DC)
Input: 3-S LiPo battery
Max Current: 55A/15S
Shaft Diameter: 4mm
Motor Resistance: 37 miliohms
Dimension: 1.4x1.42" (35mmx36mm)
Weight: 3.77oz (107g) ±.35oz (10g)
Plugs: 4mm
ESC;
Amps: 50 amp continuous
Max Amps: 65A 10 sec
Voltage Range: 9V-12.6V
BEC: 5V 2A
Motor Connectors: 4mm bullet (3)
Battery Connector: Deans®
Stutter Voltage: 9.7 volts
LVC: 9 volts
Wire Gauge: #14
Max Output Power: 500 watts
On-Resistance: 0.0015 ohms
Operating Frequency: 8KHZ PWM, 16MHZ MCU
Timing Angle: Auto
